Development Program

Development program

In July 1986 IAE confirmed to conduct a preliminary design study for a concept examining a high-bypass engine which used the V2500 core components. Prior to that study the IAE shareholders Rolls-Royce plc, Pratt & Whitney and MTU Aero Engines had examined several configuration for a high-bypass engine, including several design features like a variable fan blade pitch, a geared fan or counterrotating concepts (geared as well as ungeared). Review of these design studies in June indicated the design of such a high-bypass engine as a single-rotation, geared fan configuration with variable blade pitch. The fan diameter was expected to range from 108 to 118 in while having a bypass ratio of 18:1 to 20:1. Availability of the engine was estimated between 1992 and 1994. In December 1986 the V2500 SuperFan was officially offered to Airbus as powerplant for the Airbus A340 being developed at that time. With that offer, more design details were revealed. In addition to the V2500 core engine, IAE claimed to be able to derive all further components from proven technology. The RB.211-sized fan was to be driven through a Tyne-technology gearbox. Due to the application of existing technology, the costs as well as the risks for the SuperFan development program were appraised lower than those of the competing CFM56-5 engine. Compared to the original design's range of 7,000 nautical miles, the revised version - designated the A340-200 - was projected to have a range up to 8,000 nautical miles with full passenger load. Airbus decided on 26 December 1986 to offer the SuperFan as primary engine option for the A340. In late January, Boeing announced that it was studying the SuperFan as an option for the 150-seat 7J7 mid-range aircraft, with the SuperFan mounted under the wings instead of the aft fuselage mounting of the 7J7's baseline engine, the General Electric GE36 unducted fan. (The 7J7, not the A340, was actually IAE's primary target aircraft for the SuperFan.) Airbus was also considering the SuperFan for a 175-seat stretched version of its upcoming Airbus A320 narrowbody aircraft. First voices indicating not only the high risks associated with the new geared turbofan technology but also the potential failure to deliver the SuperFan in time appeared in February 1987. At the same time Deutsche Lufthansa and Airbus signed a preliminary contract for 15 orders and 15 options of the A340 with SuperFan engines. First deliveries were agreed for April 1992. Reinhardt Abraham (vice chairman of the Lufthansa board) stated that Lufthansa acknowledges the risks connected to the SuperFan program but got binding guarantees by IAE for the performance data and the delivery date. He also described the SuperFan as a rather conservative technology compared to the several Propfan programs that gained a lot of attention at that time. In contradiction to that, officials of Douglas Aircraft - responsible for the A340 competitor MD-11 - questioned the timetable for the SuperFan. Competitor CFM International even completely ruled out the possibility to develop the SuperFan concept in the remaining time until 1992. Despite these concerns, Airbus was able to announce at a meeting of the supervisory board on 13 March 1987 a total of 104 commitments from nine customers for their A330/A340 program. On 3 April, Northwest Airlines announced their commitment for up to 20 A340s with SuperFan engines. Of the now-ten customers for the A330/A340 program, eight ordered the A340 with SuperFan engines; in addition to Lufthansa, the list of SuperFan customers included Finnair, UTA, Sabena, and Alitalia. In a board meeting on 7 April 1987, however, the SuperFan program was officially announced as "indefinitely delayed". No official statement was made after that decision, but Ralph Robins, managing director of Rolls-Royce and board member of IAE, indicated problems with the low-pressure system posed a serious threat to deliver the engine in 1992. Airbus was formally notified about the technical risk in mid-March. He insisted that the problems IAE faced at the same time with the high-pressure compressor of the V2500 were not connected to the SuperFan delay. IAE also contended that the SuperFan was not more than an engineering study and they never committed to develop that engine. Nevertheless, further studies of the geared turbofan concept were announced. In contradiction to IAE's understanding of the SuperFan as an engineering study, the vice chairman of the Lufthansa board, Reinhardt Abraham, made clear that the Lufthansa board had received verbal as well as written confirmations that the SuperFan was a fixed development program. He admitted that Lufthansa had realized the risks in the SuperFan program but had relied on the experience and reputation of the IAE shareholding companies. When asked for the delay's reason, he revealed that in a meeting at the beginning of 1987 IAE presented several technical problems that had arisen: not only the gearbox was mentioned, but also the variable-pitch mechanism and the bypass outlet duct. But in Abraham's opinion these problems could have been solved by investing more, he blamed the problems with the V2500 high-pressure compressor as the trigger to cancel the SuperFan. Lufthansa's engineers recommended against buying the A340 because of doubts of the engine's readiness by 1992, but they were overruled by Lufthansa chairman Heinz Ruhnau with the backing of Franz Josef Strauss, who was both a Lufthansa supervisory board member and the Airbus chairman. When it was clear that the SuperFan would not be available, Airbus decided to offer the CFM56-5C on the A340. In order to achieve comparable performance data to the SuperFan-powered version, the wingspan was extended by 2.6 meters to allow a larger fuel capacity.
